It can be used on-line or off-line and switched automatically.
- Each control 170,000 points, up to 255 connected sub-control. H801RA maximum control 3412 points, up to four output ports; H802RA maximum control 4096 points, up to four output ports; H801RC maximum control 8192 points, up to eight output ports.
- SD card support FAT32, FAT16 format, the maximum capacity of 64G bytes and above, allowing up to 64 DAT files.
- Chinese and English LCD display, long press MODE key to switch.
- Support power-on times encryption.
- Can be connected to the DMX console, but also through the H802RA to DMX driver chip address.
- Support single file playback and all files loop playback, playback speed adjustable range is 1-100 frames per second, brightness adjustable range is 0-16.
- Transmission signal adopts standard Ethernet protocol, the nominal distance is 100 metres. Through the photoelectric converter, the transmission distance can reach more than 25 kilometres.
- Electrical isolation anti-interference ability, the main control and sub-control, sub-control and sub-control isolation, anti-static and lightning.
- Engineering configuration flexibility, each sub-control can control different lamps and lanterns.
